Riello UPS Sentinel Pro – SDH 3000 A5

 1.793

Riello UPS Sentinel Pro – SDH 3000 A5 – UPS
SENTINEL DUAL is the new range of high-density, double conversion online UPS, suitable for powering a wide range of devices such as servers, storage systems, telephony equipment – VoIP, network and medical systems as well as in the industrial sector.
Ideal for power supply and protection of Blade Server systems with high power supply power factor. The height of only 2U makes SENTINEL DUAL perfectly integrable in 19 “rack cabinets.
You will appreciate SENTINEL DUAL for its functional and modern design and for the performance improvements introduced by the constant technological research in the Riello UPS laboratories.
Models SDH 3000 A5
ENTRANCE
Rated power 3000 VA
Voltage 220-230-240 Vac
Voltage tolerance 140 Vac <Vin <276 Vac @ 50% LOAD / 184 Vac <Vin <276 Vac @ 100% LOAD
Frequency 50/60 Hz ± 5Hz
Frequency tolerance 50 Hz ± 5% / 60 Hz ± 5%
Power factor> 0.98
Current distortion ≤7%
BY PASS
Voltage tolerance 200 – 253 Vac
Frequency tolerance Selected frequency (from ± 0.5Hz to configurable ± 5Hz)
Number of phases 1
EXIT and INVERTER OUTPUT
Rated power 3000 VA
Active power 2700 W
Number of phases 1
Crest factor (Ipicco / Irms) 3: 1
Sinusoidal waveform
Frequency Selectable: 50 Hz or 60 Hz or self-learning
Voltage distortion with distorting load ≤ 3.5%
Voltage distortion with linear load <2%
OVERLOAD TIMES
100% <Load <110% 1 minutes
125% = Load <150% 4 seconds
Load> 150% 0.5 seconds
BATTERY
Type VRLA AGM with lead without maintenance
Recharge time 2-4 h
OTHER CHARACTERISTICS
Altitude max 1000 m at nominal power (-1% power per 100 m above 1000 m) 4000 m maximum
Black colour
USB / DB9 communication with RS232 and contacts / Slot for communication interface
Safety Compliance EN 62040-1: 2008; EN 62040-1 / EC: 2009; EN 62040-1 / A1: 2013 and Directive 2014/35 / EU
EMC compliance EN 62040-2 and Directive 2014/30 / EU
Standard equipment Power cord, serial cable, USB cable, safety manual, quick start, software on CD-ROM
Degree of protection IP20
Lightning immunity 300 joules
CE Marks
Performance Line-Interactive / Smart Active 98%
Noise level (at 1 m) <40 dBA @ 1 m
Operating temperature 0 ° C / + 40 ° C
Relative humidity 5 – 95% non-condensed
DATA
Weight 31 kg
Dimensions (h l p) 450x87x625 / 87 (2U) x450x625 mm
